Fexible Fiberglass Mesh for EIFS
Description Of Fiberglass Mesh
Flexible fiberglass mesh is a woven fiberglass mesh which is an important part of a contentious stucco or EIFS assembly. Flexible Fiberglass mesh is embedded into the base coat layer to provide reinforcement and resistance to cracking and alkali. When applied with other necessary wall components to meet code, the exterior finish will have durable, alkali resistant structure that helps minimize cracking.
alkaline-resistance
soft/standard/hard mesh
500mm-2400mm 30g/㎡-600g/㎡
Detals Of Fiberglass Mesh
Product Name: Flexibel Fiberglass Mesh
Material & Process: C-glass or E-glass woven fabric, coated with acrylic acid copolymer liquid.
Application:
● EIFS and wall reinforcement
● Roof Waterproof
● Stone Reinforcement
● Sticky mesh for EPS or wall corner
Properties :
- Polymer coated
- Leno weave
- Non-adhesive
- Durable and impact resistant
- Flame retardant
Specification Of Fiberglass Mesh
| Item No. | Density Count/25mm | Finished Weight(g/m2) | Tensile Strength *20 cm | Woven Structure | Content of Resin% (>) | ||
| warp | weft | warp | weft | ||||
| A2.5*2.5-110 | 2.5 | 2.5 | 110 | 1200 | 1000 | Leno/leno | 18 |
| A2.5*2.5-125 | 2.5 | 2.5 | 125 | 1200 | 1400 | Leno/leno | 18 |
| A5*5-75 | 5 | 5 | 75 | 800 | 800 | Leno/leno | 18 |
| A5*5-125 | 5 | 5 | 125 | 1200 | 1300 | Leno/leno | 18 |
| A5*5-145 | 5 | 5 | 145 | 1400 | 1500 | Leno/leno | 18 |
| A5*5-160 | 4 | 4 | 160 | 1550 | 1650 | Leno/leno | 18 |
| A5*5-160 | 5 | 5 | 160 | 1450 | 1600 | Leno/leno | 18 |
